Airmaster Fan 37144 Heavy-Duty Non-Oscillating Air Circulator 24" # UP24LW16-S8
Airmaster Fan 37144 Heavy-Duty Non-Oscillating Air Circulator 24-inch # UP24LW16-S8

📊 AI-POWERED MARKET ANALYSIS
• Highlight: Airmaster's 24-inch non-oscillating circulator uses a cast-aluminum prop to throw a focused column of air across a shop or warehouse aisle.
• Best For: Spot cooling workstations, drying floors, and moving stale air in industrial and commercial spaces that need directed, high-velocity flow.
• Expert Note: The die-cast airfoil moves high CFM at low watts; fixed non-oscillating aim keeps the full airstream locked on one target area.
Sale Price: $559.43
Estimated Shipping Cost: $95


Product Code: 37144
Quantity:

Description Reviews FAQ


The Airmaster UP24LW16-S8 is a 24-inch heavy duty wall mount air circulator, shipped as a unit pack with the motor, wall mounting, propeller and guard in one carton. It is a non-oscillating industrial fan for moving air across a shop floor, a warehouse aisle, a loading dock or a production line, and it is built to run continuously rather than as a comfort fan.

Specifications

  • Propeller diameter: 24-inch
  • Motor: 1/3 HP, 115 volt, single phase, totally enclosed, ball bearing
  • Speeds: three
  • Airflow: 5,588 CFM high, 4,556 CFM medium, 3,325 CFM low
  • Propeller speed: 1,110 / 900 / 700 RPM
  • Full load current: 2.5 amps
  • Power: 288 watts
  • Propeller: three blade, die cast aluminum airfoil
  • Guard finish: nickel chrome wire
  • Cord: 15 ft, three conductor SJT
  • Dimensions: 26-15/16-inch wide by 31-3/4-inch deep by 26-15/16-inch high
  • Weight: 56 lbs
  • Maximum ambient temperature: 104 degrees F
  • Listings: meets OSHA standards, UL and cUL listed
  • Performance rated to AMCA Standard 230-99
  • Warranty: 5 years
  • Catalog number: UP24LW16-S8, EDP 37144
  • Assembly required

Mounting

This unit pack is configured for wall mounting. Airmaster builds the same 24-inch fan in separate unit packs for pedestal, I-beam and ceiling mounting under different catalog numbers, so order the mounting you need rather than adapting this one.

Airmaster Fan Company traces its history to 1886 and manufactures industrial and commercial air circulation equipment in Clarklake, Michigan. Discount Cleaning Products is an Airmaster dealer and provides US-based order support.
Features
  • Energy Efficient - Lowest Watts Per CFM, Ultra Quiet Die Cast Aluminum Airfoil Propeller
  • Includes Supply Cord and Plug, Wall and I-Beam Mounts Able To Be Installed By One Individual
  • Meets OSHA Standards & UL / CUL Listed, 3 Speed Motor, 32ÔøΩ Base
  • 1/3 HP, 115V, 1 Phase, Totally Enclosed, Ball Bearing Motor
  • Patented Modular Motor End Dome for easy maintenance
    		•
